Waltco Liftgate MDL/HP Series
WLGMDLHP
A large, level-ride platform railgate with dock loading capability for easy handling of wheeled carts, bins and racks. Available in 1,600 lb, 2,000 lb, and 3,000 lb lifting capacities.
Features vertical tracks that enable the platform to move via cables or chains in conjunction with a hydraulic cylinder (or two hydraulic cylinders directly attached to the platform) for maximum strength and performance. The tracks are welded to the rear frame of a trailer, pick-up truck, service, stake or truck body to ensure optimum safety. The platform conveniently stores over the rear door during travel.
Please contact us for more information about this product.
Request a QuoteShare this product:
Waltco MDL/HP Series Specifications
| Platform Types | Alu |
| Platform Length Max (in) | 42" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 1600 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 36" |
| Platform Types | Alu |
| Platform Length Max (in) | 42" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 2000 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 36" |
| Platform Types | Alu |
| Platform Length Max (in) | 42" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 3000 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 30" |
| Platform Types | Alu |
| Platform Length Max (in) | 54" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 1600 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 40" |
| Platform Types | Alu |
| Platform Length Max (in) | 54" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 2000 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 40" |
| Platform Types | Alu |
| Platform Length Max (in) | 54" |
| Platform Width Max (in) | 89" |
| Lifting Capacities (lbs) | 3000 |
| Bed Height Max (in) | 56" |
| Bed Height Min (in) | 40" |
Waltco MDL/HP Series Features
Mid-Level Platform Rail (up to 3,000 lb. capacity)
Mid-level railgate, in a steel/aluminum platform has a lifting capacity up to 3,000 lbs. This gate is geared towards straight trucks, cube, cutaway, or step van, flat beds, and dual wheel service bodies.
Bed Heights 36"/40" - 56"
Bed height range is dependent upon the platform size. The 42" deep platform requires a minimum bed height of 36", while the 48" and 54" deep platforms require a minimum of 40" from the floor of the bed to the ground.
Modular Design
This unique gate features a hinged design, presenting a steel mainframe with an extruded aluminum platform. We also provide bolt-on platform sidebars, allowing easy replacement of extrusion boards.
Safety+ Features
This gate comes fully equipped with anti-skid treadplate, built-in toe deflector, and dedicated ground.
Above Floor Travel
Above Floor Travel
Powder Coat Finish
Powder coat finish on key liftgate components produces a high-quality, corrosion resistant finish.
Easy-Fold
Equipped with torsion spring assist to make folding and unfolding the platform simple and smooth
- Structural steel construction with zinc prime & powder coated finish
- interior body widths are 88″(EXT) & 87″(INT) and exterior width is 96″
- Interior height is 72″ high
- Floors are constructed of 10GA steel sheet with 3″ structural channel on 16″ centers
- Posts are constructed of 12GA steel sheet; exterior posts are 5″ formed posts on 36″-48″ centers, Interior posts are 3″ structural channel on 16″ centers
- Top rails are constructed of 3″ x 3″ x 1/8″ square steel tubing
- Rear corner posts are constructed of 7GA steel
- Roofs are constructed of 12GA steel with a 6″ peak
- Lockable security-style doors with 3″ x 3″ supports
- Standard 6″ steel ground rollers
